Epson FX-2190II N Network Impact Dot Matrix Printer
Part #:

C11CF38202

Specifications

• Low cost of ownership
• Up to 12 million character ribbon cartridge offers a low cost per page and reduces the frequency of user interventions
• Fast, High-Quality Printing
• Ultra-fast 9-pin printer speeds through multi-part forms and reports at up to 738 cps
• Seamless integration with new and legacy systems
• Includes Epson ESC/P, IBM PPDS and MICROLINE printer languages for greater flexibility
• Advanced Paper Handling
• Simple paper path for remarkable reliability; accommodates cut-sheet paper and continuous forms up to 7 pages thick
• Convenient and Easy to Use
• User-friendly control panel with intuitive setup and configuration features

• Extreme reliability ― long life cycle; durable design with very few moving parts; withstands dust, humidity and extreme temperatures
• Low cost of ownership ― up-to-12-million-character ribbon cartridge offers a low cost per page and reduces the frequency of user interventions
• Powerful productivity ― ultra fast, wide-format, 9-pin printer speeds through multipart forms and reports at up to 738 cps
• Seamless integration with both new and legacy systems ― includes Epson ESC/P, IBM PPDS and MICROLINE printer languages for greater flexibility
• Advanced paper handling ― simple paper path for remarkable reliability; accommodates cut-sheet paper and continuous or multipart forms up to 7 pages thick
• Easy setup and operation ― user-friendly control panel with intuitive setup and configuration features
• Low power consumption ― ENERGY STAR^® V2.0 compliant
• Multiple connectivity options ― Parallel and USB connectivity
• Serial port and Ethernet compatible ― network card supports IPv6

Eco Features

• RoHS compliant
• Recyclable product
• Epson America, Inc. is a SmartWay^SM Transport Partner

What's in the box:

• Epson FX-2190II N Impact Printer
• AC Adapter
• User’s Manual/Start Here Guide
• Setup Guide
• CD Driver
• Warranty Certificate

Print Other:

Printing Technology: 9-pin, serial impact dot matrix
Print Speed:

• Ultra Speed Draft: 738 cps (12 cpi), 615 CPS (10 cpi)
• High Speed Draft: 612 CPS (10 cpi)
• Draft: 463 CPS (10 cpi)
• Letter Quality: 115 CPS (10 cpi)

Note: Normal print speed is achieved when printer safety cover is fully closed.
Print Direction: Bidirectional logic seeking for text and graphics printing; unidirectional text or graphics printing can be selected using software commands

Characters & Lines:

Character Sets:

• 13 character tables
• 13 international countries character sets

Resident Bitmapped Fonts:

• Ultra Speed Draft: 10, 12 cpi
• High Speed Draft: 10, 12, 15, 17, 20 cpi
• Draft: 10, 12, 15, 17, 20 cpi
• NLQ (Roman/Sans Serif): 10, 12, 15, 17, 20 cpi, proportional

Bar Code Fonts: EAN-13, EAN-8, Interleaved 2 of 5, UPC-A, UPC-E, Code 39, Code 128, POSTNET, Codabar (NW-7), Industrial 2 of 5, Matrix 2 of 5
Formatting: 1/6" programmable in 1/432" increments
Line spacing: 6 lines per inch (lpi) default (8 lpi option available on FX-2190II Series Oki Data Mode Only)

General:

Sound Level: Noise: 55 dBA (ISO 7779 pattern)
Dimensions: 24.1" x 14.8" x 6.9" (W x D x H)
Weight: 20.7 lb
Safety Approvals: UL62368-1, CAN/CSA C22.2 No. 60950-1, IEC/EN62368-1 EMI: FCC part15 subpart B class A, ICES-003 Class A, EN55032 (CISPR pu.32) class A, As/NZS CISPR32 class A CE Markings: EN62368-1, EN55032 class A, EN61000-3-2, EN61000-3-3, E55024

Paper Handling Impact:

Forms: Continuous multipart, original plus 5 carbonless copies, 1 + 6 copies with pull tractor (optional), maximum thickness .018"
Width:

• Single Sheet: 3.9" to 16.5"
• Continuous: 4.0" to 16.0"
• Cut-sheet Feeder: 7.2" to 16.5"

Envelopes:

• No. 6 envelopes
• No. 10 envelopes

Length:

• Single Sheet: 3.9" to 14.3"
• Continuous: 4.0" to 22.0"
• Cut-sheet Feeder: 10.1" to 14.0"

Paper Feed Mechanism:

• Friction feed (front, rear)
• Push tractor (front, rear)
• Pull tractor (front, bottom, rear)
• Push and pull tractor (front, rear)
• Roll paper holder (optional)

Paper Feed Speed: 45 milliseconds per 1/6", 5.3" per second continuous feed
Paper Path:

• Manual Insertion: Front or rear in, top out
• Cut-sheet Feeder: Rear in, top out
• Tractor: Front rear or bottom in, top out
• Pull/Push Tractor: Front or rear in, top out

Impact Printer Details:

Software Drivers: OS Support: Microsoft® Windows Vista®; Windows® 7, XP, 8, 10; Windows Server® 2003, 2008, 2012, 2016
Printer Language:

• Epson ESC/P
• IBM PPDS
• Oki Data MICROLINE (Oki Data Mode only)

Input Buffer: Size: 128Kb
Interfaces:

• Standard: Bidirectional Parallel (IEEE 1284 Nibble Mode supported)
• USB 2.0 Optional (Factory configuration only): Serial Interface Board (FX-2190II N only)
• Network 10/100Base-TX Interface Board (FX-2190II N only)

Control Panel: Functions: Font, Pitch, Pause, Tear-off/Bin selection, Line feed/Form feed, Load/Eject, Micro-adjust, Reset, Self test, Data dump, and Default setting selection

Reliability:

MTBF: 25,000 POH (25% duty cycle)
MVBF: 52 million lines (Except printhead)
Print head life: 400 million characters at 14 dots / character
Ribbon life: 12 million characters at 14 dots / character

Power:

Rated Voltage: AC 100 V to 240 V
Rated Frequency: 50 to 60 Hz
Power Consumption:

• Operating Mode: Approx. 57 W (ISO/IEC 10561 Letter pattern)
• Ready Mode: Approx. 12 W
• Sleep Mode: < 0.04 W (Network model)
• ENERGY STAR Compliant: Certified with V2.0

Connectivity: Ethernet USB
Features: 9 Pin
Primary Use: For Business
Type : Commercial / Workgroup
Single-Function
Impact
Printer Series: FX-Series
